Overall Dimension: 30×30×10mm
Material: Impeller & Frame Plastic (Fire Rating UL94V-0)
Lead Wires: UL 1061 AWG#28 or Equivalent
Impeller: 5 Blades
Rotational direction: CCW view from impeller side
Mass: 9g
Product | Bearing | Rotational | Rated | Rated | Rated Input | Maximum | Maximum | Noise | ||
Product Number | B.S.R | RPM | VDC | Amp | Watt | CFM | m³/H | mm H₂O | in H₂O | dB-A |
SA120310-L | R | 7000 | 12 | 0.06 | 0.72 | 3.1 | 5.26 | 2.25 | 0.09 | 26.8 |
SA120310-M | R | 9000 | 12 | 0.07 | 0.84 | 4.01 | 6.81 | 3.47 | 0.14 | 32 |
SA120310-H | R | 11000 | 12 | 0.09 | 1.08 | 4.9 | 8.32 | 5.04 | 0.2 | 37.4 |
SA120310-U | R | 13000 | 12 | 0.12 | 1.44 | 5.77 | 9.8 | 6.46 | 0.25 | 41.3 |
SA120310-S | R | 15000 | 12 | 0.16 | 1.92 | 6.64 | 11.28 | 8.4 | 0.33 | 44.9 |
