Overall Dimension: 92×92×38mm
Material: Impeller & Frame Plastic (Fire Rating UL94V-0)
Lead Wires: UL 1007 AWG#24 or Equivalent
Impeller: 5 Blades
Rotational direction: CCW view from impeller side
Mass: 230g
IP-Rating: IP68
Product | Bearing | Rotational | Rated | Rated | Rated Input | Maximum | Maximum | Noise | ||
Product Number | B.S.R | RPM | VDC | Amp | Watt | CFM | m³/H | mm H₂O | in H₂O | dB-A |
SC120938-M | B | 8000 | 12 | 0.85 | 10.2 | 112.5 | 191 | 32.7 | 1.29 | 59.7 |
SC120938-H | B | 10000 | 12 | 1.65 | 19.8 | 140.7 | 238.9 | 51.1 | 2.01 | 64.5 |
SC120938-U | B | 12000 | 12 | 2.8 | 33.6 | 168.8 | 286.6 | 73.6 | 2.9 | 68.5 |
SC240938-M | B | 8000 | 24 | 0.45 | 10.8 | 112.5 | 191 | 32.7 | 1.29 | 59.7 |
SC240938-H | B | 10000 | 24 | 0.85 | 20.4 | 140.7 | 238.9 | 51.1 | 2.01 | 64.5 |
SC240938-U | B | 12000 | 24 | 1.4 | 33.6 | 168.8 | 286.6 | 73.6 | 2.9 | 68.5 |
