DS867-5B

Unlocking Methods：Card Unlocking (IC Card), 485 UnlockingEmergency Unlocking (Mechanical Key)

Main Materials：Base: Zinc AlloyHandle: Zinc Alloy

Technical Parameters：Working Voltage: DC12V Working Current: ≤0.3A Operating Temperature: -10~70℃ Protection Class: IP50

Interface Definition：Type: RJ45 Connector 1 (Black Wire): GND 5 (Red Wire): VCC  7(Yellow Wire): 485-  8(White Wire): 485+

Notes：The operating frequency of the IC card is 13.56MHz, complying with the ISO 14443 TYPE-A standard.
