DS864-8-7F-3

Unlocking Method: Remote Unlocking, Emergency Unlocking (Mechanical Key/Electronic Key)

Main Materials: Handheld Part: Aluminum Alloy Base: Zinc Alloy Steel Plate: Q235

Technical Parameters: Working Voltage: DC5V Working Current: ≤0.2A Operating Temperature: -20~65℃ (Front/Back) Protection Class: IP55

Interface Definition: Type: M12-8-hole Anti-loosening Wiring:Red Wire: Power Input Positive Terminal Black Wire: Power Input Negative Terminal Gray Wire: Motor Locking (Control) Blue Wire: Motor Unlocking (Output Terminal) White Wire: Unlocking (Output Terminal) Yellow Wire: EmptyGreen Wire: Motor Control Brown Wire: Alarm

Notes：Unlocking: When the handset is open, the gray wire and brown wire are connected; when the handset is closed, the gray wire and brown wire are disconnected (can be customized)Matching Padlocks: MS3314, MS345-5, MS8940, MS64-4-60-P, MS5829-1, MS5829-2, MS839, MS8212, MS731, MS712
