DS899

Unlocking Methods：Card Unlocking (IC Card), 485 UnlockingEmergency Unlocking (Mechanical Key)

Main Materials：Base: Zinc AlloyHandle: Zinc AlloyLock Bolt: SUS304

Technical Parameters：Working Voltage: DC12V Working Current: ≤0.25A Operating Temperature: -20~65℃ Protection Class: IP65 Anti-Tamper Grade: Grade B

Interface Definition：Type: RJ45 ConnectorWire  1 (White): 485+Wire  2 (Yellow): 485-Wire  3 (Red): VCCWire  8 (Black): GND

Notes：The operating frequency of the IC card is 13.56MHz, complying with the ISO 14443 TYPE-A standard.
