DS782

Unlocking Methods: Remote Unlocking, Emergency Unlocking (Mechanical Key)

Main Materials: Base: Q235 (Electroplated) Lock Core: Zinc Alloy (Electroplated)

Technical Parameters: Working Voltage: DC12V Working Current: ≤0.7A Operating Temperature: -20~60℃ Protection Class: IP5X

Interface Definition: Type: XH2.54-2Y or RJ45Red Wire: VCCBlack Wire: GND

Notes: Do not power the electronic lock for an extended period; the power-on time should not exceed 30 seconds
