Structure: 90° rotation for opening/locking, supports left/right (RL) door opening, IP65 protection, with padlock device.
Material: Zinc alloy (base, handle), carbon steel (steel bolt, padlock seat).
Surface: Base and handle with nano matte finish; steel bolt and padlock seat white zinc-plated.
Adaptation: Steel bolt defaults to S1B45Y07019
Performance Parameters
Maximum static load | 220N |
Fixed nut recommended tightening torque | 20N.m |
Maximum input torque | 15N.m |
