Structure: Rotate handle to open/close, supports RL bidirection, with/without padlock (lock core with/without return function optional).
Material: Zinc alloy (base/handle/spindle/slide cover/transmission shell), carbon steel (obstruction bar/steel bolt/connector), stainless steel (lock catch).
Surface: Handle/spindle spray - painted, base/slide cover nano matte; compatible with K580 key.
Performance Parameters
Handle tension | ≤315N |
Handle torque | ≤22N.m |
Optional Configurations
lock core without | with return | |
With padlock | MS830 - 6P - 2 | MS830 - 6P - 1 |
Without padlock | MS830 - 6 - 2 | MS830 - 6 - 1 |
