MS731-6

Product description

Structural Operation: 180° rotation of the lock cylinder; pressing the button makes the handle pop up, and rotating the handle to open or close. The left-right positions of the transmission bar and steel bolt can be adjusted, supporting left-opening doors (MS731 - 6 - Z) and right-opening doors (MS731 - 6 - Y).

Material & Surface: Zinc alloy is used for the base, handle, and button; Q235 steel for the pressure plate; carbon steel for the steel bolts and transmission bars. The base and other components undergo nano-matte treatment, and the steel bolts are white zinc plated, ensuring corrosion resistance and durability.

Performance Parameters: Handle load-bearing pull force ≤ 350N, torque ≤ 25N·m.

Protection & Compatibility: IP40 protection rating; compatible with X060 keys, supporting left-right (R/L) installation.

Installation Features: Clear hole dimensions for easy door installation.
