Structure: Lock core rotates 90° to open/lock, with automatic locking function, supports left/right (R/L) installation; HP001 pull tab and WP002 waterproof cover are optional.
Material: Zinc alloy (base, lock core), carbon steel (steel bolt).
Surface: Base, lock core, steel bolt with bright chrome plating.
Adaptation: Optional K15 series keys.
Performance Parameters
Maximum static load | 270N |
Maximum input torque | 9N.m |
Fixed nut tightening torque | 20N.m |
Optional Configurations
Accessories: HP001 pull tab (optional), WP002 waterproof cover (optional); Steel bolts have left/right versions.
Color: Base, lock core, steel bolt bright chrome plated .
