Material: Base, lock core: Zinc alloy; Handle: PA; Transmission shaft: Zinc alloy
Surface Treatment: Base: Black (matte) spray coating; Lock plunger: Zinc-plated (white)
Structure Description: Rotate 90° to open or close
Remarks: Default key: K190
| Performance Parameters | |
| Specification | Details |
| Maximum Static Load Capacity | 270N |
| Maximum Input Torque | 30N·m |
| Recommended Tightening Torque for Fixing Nut | 20N·m |
