Material: Zinc alloy base, handle; carbon steel pressure plate, bolt
Surface Treatment: Powder-coated (black paint) base, handle; white zinc-plated pressure plate, bolt
Structure: Quick opening, easy to install; bent bolt is suitable for different stop heights
Note: Bolt ERP Material No. S1B73Y00001 (Default)
| Performance Parameters | |
| Handle Bearing Tension | ≤125N |
| Handle Bearing Torque | ≤17N·m |
| Maximum Static Load | 150N |
