Material: Zinc alloy base, lock core, carbon steel bolt
Surface Treatment: Sandblasted nickel-plated base, handle, button; white zinc-plated bolt
Structure: Quick opening, easy installation; Adjustable bolt screw to change stop height and bolt center distance
Performance Parameters
Handle Bearing Tension | ≤900N |
Maximum Static Load | 350N |
Feature Description | Product Model | Left-handed Opening | Right-handed Opening |
With Lock Core | MS707 | MS707Z3I000001 | MS707Z3I000002 |
With Sealable Button | JMS707 | MS707Z3I000003 | MS707Z3I000004 |
