DS635-9D

Unlocking Methods：Power-on Unlocking, Emergency Unlocking

Main Materials：Lock Body: Q235, Electrophoretic Black

Technical Parameters：Lock Bearing Capacity: ≥600N Load Unlocking: ≥100N Working Voltage: DC12±1V Working Current: ≤2.5A Neutral Salt Spray: 48h Operating Temperature: -20~70℃Executive Mechanism: Solenoid Valve

Interface Definition：Red Wire: VCC Black Wire: GND Blue Wire: Status Output Wire White Wire: Status Output Wire

Notes：The blue and white wires are open-circuited when the lock is locked, and short-circuited when the lock is unlockedThe top pin is optional
