DS635-6

Unlocking Methods：485 Unlocking, Emergency Unlocking

Main Materials：Lock Bolt: Stainless Steel Fixing Buckle: Stainless SteelLock Body: Q235

Technical Parameters：Working Voltage: DC9-16V Working Current: ≤0.1A Lock Bolt Bearing Capacity: ≥1500N Communication Interface: RS485 Operating Temperature: -10~85℃

Interface Definition：Type: RJ45 Socket Wire 1: 485+ Wire 2: 485- Wire 3: VCC Wire 4: 485+ Wire 5: 485- Wire 8: GND

Notes：Can be used with mechanical locksThe top pin is optional
