Unlocking & Locking Methods：485 LockingBluetooth LockingEmergency Unlocking (Mechanical Key)
Main Materials：Base: Zinc Alloy Handheld Part: Zinc Alloy Steel Plate: Q235
Technical Parameters：Working Voltage: DC12VWorking Current: ≤0.3AOperating Temperature: -20~60℃Protection Class: IP65
Interface Definition：Type: Dispersed Wires Wiring:Red: VCC Black: GND Gray: / Orange: / Blue: DO Green: DO White: 485- Yellow: 485+
Notes：Compatible Mounting Hole Positions: MS834-1, MS834-4-60-P, MS840, MS864-4-60-P, MS829-1, MS8212, MS839, MS259, MS731, MS712
| Performance Parameters | |
| Specification | Details |
| Operating Voltage | DC 12V |
| Operating Current | ≤0.3A |
| Operating Temperature | -20℃+60℃ |
| Protection Level | IP65 |
| Technical Parameter Item | |
| Component | Designation |
| MBO1 Transparent Part | DSS64-8-F-5 |
| SB345002 Locking Component Set | DSS64-8-FT-F-5 |
