Material: Zinc alloy base, handle, shaft; positioning piece, carbon steel pin
Surface Treatment: Matte black (base, handle); galvanized (shaft, positioning piece, pin)
Structure Description: Rotate the handle 90° to open and lock; adjust the direction of the positioning piece to switch left/right opening
Note: Default configuration: K14 keys
| Performance Parameters | |
| Specification | Details |
| Handle Pull Force | ≤300N |
| Maximum Handle Torque | ≤20N·m |
| Maximum Load Capacity | 300N |
