Material: Zinc alloy base, lock cylinder; carbon steel pin
Structure Description: Rotate the lock cylinder 90° to open or lock
Note: Equipped with K15
| Performance Parameters | |
| Specification | Details |
| Maximum Static Load Capacity | 150N |
| Maximum Input Torque | 6N·m |
| Recommended Tightening Torque for Fixing Nut | 20N·m |
