Material:Base, lock core, lock plunger: Zinc alloy
Surface treatment: Chromium-zinc alloy lock core, base, steel bolt
Structure Description:Rotate 270° to open
Remarks:Default key: K15
| Performance Parameters | |
| Specification | Details |
| Maximum Static Load Capacity | 300N |
| Maximum Input Torque | 9N·m |
| Recommended Tightening Torque for Fixing Nut | 20N·m |
