Material: Base: Zinc alloy; Lock plunger: Carbon steel
Surface Treatment: Base: Bright chrome plating; Lock plunger: Zinc-plated (white)
Structure Description: Rotate 90° to open or lock
Remarks: Default key: K080
| Performance Parameters | |
| Specification | Details |
| Maximum Static Load Capacity | 160N |
| Maximum Input Torque (Knob Type) | 10N·m |
| Recommended Tightening Torque for Fixing Nut | 20N·m |
