S840-2 Multipoint systems

Multipoint systems

Specification

Material: Zinc Alloy handle,housing,shaft,

lock tonge, carbon steel cam, timing chain

Surface: Mel Black powder coat for handle and housing,

white Zinc plated for lock tongue and cam.

Structure description: Rotate the handle to open and close the door

Notes: Maximum Static Load

Cam loading: 270N

Handle torque: 35N.m

Handle loading: 400N
