Material: Zinc alloy base, handle, lock head components; carbon steel shaft (powder coating)
Surface Treatment: Base, handle: bright galvanized finish; lock head components: bright galvanized finish; steel pin: galvanized (white); shaft: powder coating
Structure Description: Rotate the handle to open and close the door panel
Note: Default configuration: TC04-1 lock head, K040 keys
| Performance Parameters | |
| Specification | Details |
| Tensile Force Capacity of Handle | ≤225N |
| Torque Capacity of Handle | ≤20N·m |
| Maximum Static Load (Steel Ball Type) | 270N |
Note: The protective cover of the locking head helps protect the lock core.
