Material: Zinc alloy base, lock cylinder, handle; carbon steel pin; PA plastic
Surface Treatment: Spray coating (black finish) for base, lock cylinder, handle; galvanized finish for carbon steel pin
Structure Description: Rotate the lock cylinder 90° to achieve opening or locking; equipped with a locking function
| Performance Parameters | |
| Specification | Details |
| Maximum Static Load Capacity | 360N |
| Maximum Input Torque | 8N·m |
| Recommended Tightening Torque for Fixing Nut | 20N·m |
