Material: Zinc alloy base, lock cylinder; carbon steel pin; PA plastic
Surface Treatment: Spray coating (blue-gray finish) for base and lock cylinder; galvanized finish for carbon steel pin
Structure Description: Rotate the lock cylinder 90° to achieve opening or locking; equipped with a locking function
Note: Optional K15-1 series keys
| Performance Parameters | |
| Specification | Details |
| Maximum Static Load Capacity | 300N |
| Maximum Input Torque | 11N·m |
| Recommended Tightening Torque for Fixing Nut | 20N·m |
